Description
Bovie A952-V Veterinary Electrosurgical Generator
The Bovie A952-V Veterinary Electrosurgical Generator is a High Frequency Desiccator with cutting ability. You might call it a split personality. One half of the unit is a high frequency desiccator, an upgrade to our very popular Aaron?940. The other half is a Bovie Generator, giving you 50 watts of cutting power and coag capabilities ? plenty of power for most cutting procedures performed in the Veterinarian?s office.
| MONOPOLAR | WATTS | VPEAK MAX VOLTAGE | CREST FACTOR (TYPICAL) | FREQUENCY (KHZ) |
|---|---|---|---|---|
| Cut I | 50 | 1600V | 2.2 – 20% | 343kHz – 10% |
| Blend | 50 | 2100V | 3.5 – 20% | 368 kHz – 10% |
| Coagulation | 50 | 2900V | 5.2 – 20% | 340 kHz – 20% |
| Spray Coagulation | 40 | 6300V | 9.5 – 20% | 410 kHz – 10% |
| MONOPOLAR | WATTS | VPEAK MAX VOLTAGE | CREST FACTOR (TYPICAL) | FREQUENCY (KHZ) |
|---|---|---|---|---|
| Bipolar | 40 | 950V | 5.5 – 20% | 368kHz – 10% |
| Micro Bipolar | 40 | 300V | 2.6 – 20% | 338 kHz – 10% |
Line Frequency:
50-60 Hz
Output Frequency:
304-451 kHz
Line Voltage:
100-240 VAC
Output Power:
Cut: 50 watts
Blend: 50 watts
Coagulation: 50 watts
Fulguration: 40 watts
Bipolar: 40 watts
BovieNEM
Contact Monitoring Systems:
10 ohms or less over entire operating range
Range/Trip Point:
(10C to 40C)
Cooling System:
Passive Cooling
Technology:
Isolated RF Output
Height: 188 mm (7.40 in.)
Width: 228 mm (8.98 in.)
Depth: 105 mm (4.13 in.)
Weight: < 2.26 kg (< 5 lbs.)
Warranty:
4 years
